European Electric Hoist for Sale | Wire Rope Hoist, FEM 1Am–4m, 1T–20T
European‑standard wire rope hoist is high‑performance modular lifting hoist designed according to FEM 1Am‑4m / ISO M3‑M7 European material‑handling standards. Adopting integrated three‑in‑one motor‑reducer‑brake unit, Yangyumech wire rope hoist covers capacity from 1‑20 ton. Compact lightweight structure, dual‑speed lifting, long‑life duty cycles up to 500 000 times. Widely matched with overhead crane, gantry crane and jib crane for modern industrial workshop lifting tasks.
• Capacity(t): 1-20t
• Working Class(FEM): 1Am-4m
• Working Class (ISO/GB): M4-M7
• Lifting Height (m): 6/9 12/18
• Trolley Speed (m/min): 2-20
Description
Typical Application & Compatible Crane Types
Yangyumech european‑standard wire rope hoist can be installed on multiple crane systems:
‑ Single‑girder & double‑girder overhead EOT cranes
‑ Box‑type gantry cranes, rubber‑tyred gantry cranes
‑ Column‑mounted & wall‑mounted jib cranes
‑ KBK modular light workstation crane systems
Typical end‑user industries: machinery manufacturing, equipment assembly workshops, warehouses, ship‑repair yards, steel‑processing plants.
Ambient working temperature:‑20℃ ~ +40℃, mainly for indoor use; anti‑corrosion version for sheltered outdoor.
European standard high duty electric hoist is used for Mechanical Workshop. It employs motor of hoisting mechanism and reducer imported ABM from Germany. The integrated and compact design of hoisting motor, reducer, reel and limit switch saves space for the user. Modular design increases the reliability of mechanism meanwhile reduces the time and cost for maintaining.
The European Standard Electric Wire Rope Hoist is an innovative solution designed to meet the demanding needs of modern industrial environments. Built to European standards, this hoist provides exceptional safety and performance, making it ideal for a variety of applications including factories, warehouses, and shipyards.
With a load capacity ranging from 1 to 20 tons, the European Standard Electric Wire Rope Hoist is capable of handling heavy loads with ease. The lifting height can be customized between 6 and 18 meters, and the hoist offers variable speeds from 0.8 to 5 m/min, ensuring precise and efficient operation. The hoist is constructed using aviation-grade steel wire ropes and alloy drums, ensuring a secure lifting structure and long-term durability. The low noise planetary gearbox provides smooth and stable movement, while the optimized transmission efficiency enhances overall performance.
Designed for longevity, can perform for 20,000 to 500,000 duty cycles, making it a cost-effective and reliable investment for any industrial operation. Whether lifting heavy machinery, positioning equipment, or handling materials, the KRQ7 European Standard Electric Wire Rope Hoist delivers superior performance and safety.
Custom Purchasing Process
1. Submit inquiry: Provide rated lifting capacity, lifting height, headroom type(standard / low‑headroom), FEM duty‑class requirement, compatible crane type, control‑mode, power‑supply voltage and special demands(explosion‑proof / VFD).
2. Custom technical drawing & quotation: Our engineering team delivers tailored specification sheet and formal quotation within 24 working hours.
3. Order confirmation: Confirm technical specifications, delivery cycle and commercial terms.
4. Production & strict‑quality‑inspection: Component incoming inspection, complete factory function test before shipment.
5. Seaworthy export‑packaging & ocean shipment, deliver full‑set of CE‑relevant export certification documents.
6. After‑sales support: Operation‑instruction manual, remote‑technical‑service and long‑term spare‑parts supply.
Features
1. European FEM‑standard design with complete set of safety interlock mechanisms.
2. Rated lifting capacity covers from 1 ton up to 20 tons.
3. Customizable lifting height ranging from 6 m to 18 m or higher upon request.
4. Dual‑speed lifting speed adjustable from 0.8 to 5 m/min; VFD stepless speed optional.
5. Robust mechanical design supports long service life of 20 000‑500 000 duty cycles.
6. Multi‑layer safety suite: emergency brake, reliable overload‑limiter, upper/lower travel limit switches.
7. Flexible operation choices: pendant push‑button, wireless radio remote control or operator cabin.
8. Low‑noise planetary gearbox for smooth and stable lifting & trolley travelling performance.
9. Modular structure supports customized hoist trolley, electrical components and special‑environment upgrades.
10. Two‑in‑one / three‑in‑one compact motor‑reducer‑brake unit saves overhead space for workshop.
Wire Rope Hoist vs Chain Hoist: Which Electric Hoist Do You Need?
Choosing between a wire rope hoist and an electric chain hoist depends on your capacity, frequency, and environment requirements.
Choose a European Standard Wire Rope Hoist When:
– Lifting capacity exceeds 3 tons (chain hoists typically max out at 3–5 tons)
– You require lifting heights greater than 12 meters
– The application involves high-duty continuous operation (FEM 1Am+ rating)
– Precise positioning is critical (dual-speed or VFD control)
– You need longer wire rope service life in high-cycle environments
– The hoist is mounted on an overhead crane (most overhead cranes use wire rope hoists)
Choose an Electric Chain Hoist When:
– Lifting capacity is 250 kg to 5 tons
– Working height is under 12 meters
– The environment is corrosive (stainless steel chain available)
– The hoist is used manually at a fixed workstation rather than on a crane
– Budget is the primary constraint
– Weight is critical (chain hoists are lighter and more compact)
Yangyumech manufactures both European standard wire rope hoists (1T–12.5T) and electric chain hoists. Tell Yangyumech your capacity, lifting height, duty cycle, and working environment, and Yangyumech’s team will recommend the right hoist type for your application.
Technical Data
| Rated load S. W.L (Kg) | Work level | Lifting Height | Lifting speed | Traveling speed | |
|---|---|---|---|---|---|
| FEM | ISO | m | m/min | m/min | |
| 2000 | 1 AM- 4M | M3-M6 | 6/9/12/15/18 | 0. 8/5 | 2~20 |
| 3200 | 1 AM- 4M | M3-M6 | 6/9/12/15/18 | 0. 8/5 | 2~20 |
| 5000 | 1 AM-4M | M3-M6 | 6/9/12/15/18 | 0. 8/5 | 2~20 |
| 6300 | 1 AM-4M | M3-M6 | 6/9/12/15/18 | 0. 8/5 | 2~20 |
| 8000 | 1 AM-4M | M3-M6 | 6/9/12/15/18 | 0. 8/5 | 2~20 |
| 10000 | 1 AM-4M | M3-M6 | 6/9/12/15/18 | 0. 8/5 | 2~20 |
| 12500 | 1 AM-3M | M3-M5 | 6/9/12/15/18 | 0. 8/5 | 2~20 |
| 16000 | 1 AM-3M | M3-M5 | 6/9/12/15/18 | 0. 66/4 | 2~20 |
| 20000 | 1 AM-3M | M3-M5 | 6/9/12/15/18 | 0. 66/4 | 2~20 |
Purchasing Process
Our Crane Certifications
Our cranes (overhead crane, gantry crane, jib crane and electric hoist) are fully certified to meet international and local manufacturing standards. We hold complete qualification documents to guarantee product safety and reliable quality for global buyers. Below are our key certifications:
- ISO 9001 Quality Management System Certificate
- ISO 45001 Occupational Health & Safety Management Certificate
- Special Equipment Type Test Certificate for Lifting Machinery
- Manufacturing License for Lifting Equipment
- Third‑party Independent Audit Certificates
- Complete Export‑Oriented Qualification Documents
Our Custom Visit
We welcome worldwide customers to visit our manufacturing workshop. You can check crane production processes, raw materials and finished products face‑to‑face with our engineering team.
- Customized Crane Solution Design
- Professional Technical Consultation & Quotation Support
- Production Tracking & Quality Supervision
- Overseas Shipping & Complete Document Service
- After‑sales Technical Support & Guidance
FAQs for European‑Standard Wire Rope Hoist
Please provide rated lifting capacity, lifting height, standard‑headroom or low‑headroom trolley, FEM duty‑class, compatible crane type, control‑mode, power‑supply voltage and special‑environment requirements.
FEM duty‑class defines hoist design service life by total duty cycles. FEM 1Am is for light‑intermittent maintenance‑use; FEM 3M suits heavy‑duty multi‑shift daily‑production scenarios. Wrong duty‑class selection will lead to early wear‑out of components.
Select low‑headroom trolley version if your workshop building ceiling height is limited, it maximizes effective hook lifting travel within limited overhead clearance.
Wire‑rope hoist is better for higher tonnage, long lifting‑height and high‑frequency use when mounted on overhead / gantry crane. Electric chain hoist fits light‑load fixed‑point workstation lifting. Please refer our comparison table above.
Yes, we can supply complete explosion‑proof electrical & mechanical components for hazardous‑zone workshop applications.
